Parent Layer: Transportation

Name: Trails 2050

Display Field: TrailName

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The Trails 2050 Network was adopted by City Council on November 19, 2024 as part of the Trails & Connectivity (TConn) plan. The Trails 2050 layer contains the following attribute information:Project Category - category assigned by Alta during the TConn study (options include: Bridge the Gaps, Complete the System, Connect Neighborhoods, Connect Open Spaces, Improve Blueway Connections, or null)Facility Type - type of trail/path proposed - Options include: Bike Boulevard, Bike Lane, Blueway, Separated Facility (Path or Bikeway), and Shared Use Path/Trail. Bike Boulevards - are streets with additional signage and traffic calming measures; bikers share-the-road with motorists.Bike Lanes - have designated on-street areas adjacent to driving lanes; they are marked with lines, symbology, and signage to increase awareness among motorists that cyclists may be present.Blueways - designated waterways that can be used by and accessed by non-motorized watercraft such as kayaks, canoes, paddleboards, etc.Separated Facilities - can come in the form of two subcategories, separated bike lanes and sidepaths. Separated bike lanes are found in the roadway but have physical barriers separating them from driving lanes; they may be separated by curbs, bollards, planters and other means. Side paths are shared use paths located along a roadway; they may have paved, concrete, or natural surfaces.Shared Use Paths (SUP)/Trails: provide space for walkers, runners, bikers, and other path users; typically do not follow roadways. They may be paved, concrete or natural surfaces.Symbology Type - the facility types are condensed into five main categories for display purposes. They are: Paved SUP/Trail, Paved SUP/Trail 2050, Separated Facility, Separated Facility 2050, Bike Lane, Bike Lane 2050, Bike Boulevard, Bike Boulevard 2050, and Blueway). "2050" at the end of the symbology layer indicates that the path does not exist but it is part of the adopted Trails & Connectivity 2050 Plan. Trail Name - if it has one; many trails are not named.Roadway - name of major roadway the trail follows; off-road indicates the trail does not follow a roadwayStart - crossroad where the trail starts. For N/S trails, the northern most street intersection; for E/W trail, the western most street intersection.End - crossroad where the trails ends. For N/S trails, the southern most street intersection; for E/W trails, the eastern most street intersection.Status - Trail Status in the development process. Trails progress through the following categories: Trails 2050, Funded, In Design, Under Construction, Undergoing Improvements, Existing, TimeLine - when trail is expected to begin the development processNotesFundedInDevelopment - funding sourceLength (miles) - length of trailsThis layer is a combination of the trails network proposed by Alta and adopted with the Trails & Connectivity Plan and the existing trails from the previous 2050 Trails plan. Each existing trail was examined to see if should be included as part of the trail network. The layer symbology was expanded to include existing trails depicted with solid lines in the categories and colors adopted. Some existing trails included in the 2050 Trails Plan were not included. These primarily included on-road bike lanes lacking proper demarcation, signage, unsafe traffic speeds and other elements deemed critical for biker safety. Updates:The Chesapeake City Council renamed the Western Branch Trail to the Dr. John de Triquet Memorial Trail at Western Branch on 3/23/2026. Dr John de Triquet was serving as Vice Mayor when he passed away in August 2025. The Trails 2050 layer was updated on 3/25/2026.

Service Item Id: 98af486085f54f1888458af16e7441e1

Copyright Text: Planning, Trails and Connectivity Study, Alta

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.2079478566895887E7
YMin: 3366886.09370856
XMax: 1.219526011157906E7
YMax: 3481489.7496713996
Spatial Reference: 102747  (2284)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: SymbolClass
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Bike Boulevard 2050
  Label: Bike Boulevard 2050
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [250, 171, 25, 255]
  Width: 1
• Value: Bike Lane 2050
  Label: Bike Lane 2050
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [69, 163, 217, 255]
  Width: 1
• Value: Blueway 2050
  Label: Blueway 2050
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [242, 214, 0, 255]
  Width: 2
• Value: SUP/Trail
  Label: SUP/Trail existing
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [16, 176, 120, 255]
  Width: 1
• Value: SUP/Trail 2050
  Label: SUP/Trail 2050
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [16, 176, 120, 255]
  Width: 1
• Value: Separated Facility
  Label: Separated Facility existing
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [56, 98, 174, 255]
  Width: 1
• Value: Separated Facility 2050
  Label: Separated Facility 2050
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [56, 98, 174, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ProjectCategory ( type: esriFieldTypeString, alias: ProjectCategory, length: 255 )
• FacilityType ( type: esriFieldTypeString, alias: FacilityType, length: 255 )
• SymbolClass ( type: esriFieldTypeString, alias: Symbology Type, length: 255 )
• TrailName ( type: esriFieldTypeString, alias: Trail Name, length: 255 )
• Roadway ( type: esriFieldTypeString, alias: Roadway, length: 255 )
• Start ( type: esriFieldTypeString, alias: Start, length: 255 )
• End_ ( type: esriFieldTypeString, alias: End, length: 255 )
• Status ( type: esriFieldTypeString, alias: Status, length: 255 )
• Timeline ( type: esriFieldTypeString, alias: Timeline, length: 255 )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 255 )
• FundedInDevelopment ( type: esriFieldTypeString, alias: FundedInDevelopment, length: 255 )
• Lengthmi ( type: esriFieldTypeDouble, alias: Length (miles) )
• CREATED_USER ( type: esriFieldTypeString, alias: Created User, length: 255 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• LAST_EDITED_USER ( type: esriFieldTypeString, alias: Last Editor, length: 255 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: Last Edited Date, length: 8 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
